Technical Specifications
4
ekr CON 100 – Installation and Operating Manual 27/130
4.1.4 Analogue Inputs
Servo center transducer OMG8, CK 37 (terminal strip X3)
input signal According to Namur specifications
Power supply According to Namur specifications
Connection Spring-cage terminal block
Position feedback EMS18, EMS21, EMS22 (terminal strip X2)
Input signal 0…10V⎓ or 0…18V⎓
(automatic voltage selection
depending on the actuator used)
Power supply +24V⎓
Connection Spring-cage terminal block
4.1.5 Digital Inputs
Digital inputs (terminal strip X1)
Remote control <4V⎓ (Low), >8V⎓(High)
Controller interlock <4V⎓ (Low), >8V⎓(High)
Switching is carried out via the
hardware, i.e. not via the
processor or the software.
Galvanic isolation None!
Connection Spring-cage terminal block
4.1.6 Output Motor Output Stage
Socket X103 / terminal strip X4
Voltage ±24V⎓
(with lower power supply, the
maximum adjustment force of
the actuator reduces)
Current Max. 1.9A (Peak current 7A)
Protection Automatic electric switching off
after approx. 400 ms if over-
current occurs with motor
current in one direction
(no polarity change):
> 1.9A (EMS22, ECOEMS22)
> 1.7A (EMS21)
> 1.1A (EMS10, EMS18)
Connection Socket M12 /
spring-cage terminal block
Brushless motor connection, see chapter X4 - Brushless motor /
DC, page 57.
