Operation
9
ekr CON 100 – Installation and Operating Manual 97/130
9.8 Selecting the Operating Mode
9.8.1 Manual Mode
In this operating mode, you can change the position of the guiding
device.
WARNING
Danger of death from actuator movements!
Parts of your body could be crushed, cut or hit.
►
Make sure that no persons remain in the vicinity of the pivot /
traversing area of machine components that are positioned by
the actuator.
1. Press the Manual mode key.
The LED of the key will illuminate.
The controller switches to manual mode.
2. Using the arrow keys, move the guiding device to the desired
position.
9.8.2 Automatic
In this operating mode, automatic web guiding is carried out
depending on the guiding mode selected (guiding to the left or
right web edge, web center-line guiding, line or contrast guiding).
WARNING
Danger of death from actuator movements!
Parts of your body could be crushed, cut or hit.
►
Make sure that no persons remain in the vicinity of the pivot /
traversing area of machine components that are positioned by
the actuator.
›› The desired guiding mode is selected (see Selecting the Guiding
Mode, page 96).
►
Press the Automatic key.
The LED of the key will illuminate.
ð The controller switches to automatic mode.
