8
Commissioning
66/130 ekr CON 100 – Installation and Operating Manual
8.5 Commissioning the Actuator Without Position Feedback
Actuators without positions feedback:
EMS10, ECO EMS 22
8.5.1 Set the Guiding Direction for Center Positioning
If you use a servo center transducer (OMG 8, CK 37), you have to
check the guiding direction for the operating mode Center
Positioning.
Checking the guiding direction
WARNING
Danger of death from actuator movements!
During function tests, parts of your body may be crushed, cut or hit.
►
Make sure that no persons remain in the vicinity of the pivot /
traversing area of machine components that are positioned by
the actuator.
►
Press the Center positioning key and observe the guiding device.
The guiding device must move into its central position.
If the guiding device moves into one of its end positions then you
have to reverse the guiding direction.
Reversing the guiding direction
►
Change DIL switch S1.2 on the processor board of the controller
(see Setting the DIL Switches, page 64).
