Technical Specifications
4
ekr CON 100 – Installation and Operating Manual 35/130
Type Stroke
[mm]
Gearbox
ratio
Spindle
dimensions
[mm]
Nominal
actuating force
[N]
Nominal
adjusting speed
[mm/s]
EMS21
100
2.5:1
20 x 5
840 20
5:1 1,680 10
200
2.5:1 840 20
5:1 1,680 10
EMS22
100
2.5 : 1
20 x 5
1,125 20
5 : 1 2,250 10
200
2.5 : 1 1,125 20
5 : 1 2,250 10
EMS23
195*
7 : 1
25 x 5
4,300 20
10 : 1 10,000 15
295*
7 : 1 4,300 20
10 : 1 10,000 15
ECOEMS22
195 5 : 1 20 x 5 1,500 12
* Tolerance stroke max. -2 %
4.5 Emissions
Continuous sound level (A evaluated, equivalent)
< 70 dB(A)
4.6 RoHS Conformity
This product complies with the EC Directive 2011/65 (so-called
RoHS* Directive). The limits values for hazardous substances in
electrical and electronic equipment specified there are not
exceeded by this product.
* Abbreviation for Restriction of Hazardous Substances
