Parts of the Basket
(A) Basket Rod (tag side)
Secures the cloth basket to the tips of the basket arm.
(B) Basket Arm
Retains the basket rod (tag side).
By changing the length and the angle, you can make the basket suitable for various conditions.
(C) Basket
A cloth tray that catches ejected documents.
(D) White Tag
Marks indicating basket attachment orientation.
(E) Basket Rewind Button
Press this button when rewinding the basket after it has been wound on the basket rod (tag side).
(F) Basket Rod (cord side)
Secures the cloth basket on the rod holder.
(G) Rod Holder
Retains the basket rod (cord side).
For instructions on how to use the basket, see "Using the Basket" and "Example Basket Configurations".
When not using the basket, you can lower it and store alongside of the stand. (See "Storing the Basket.")
