Remove a Jammed Sheet
If a sheet jams, follow the steps below to remove it.
1.
Turn off the power to the printer.
1.
Turning the Printer On and Off
2.
Open the top cover.
2.
3. If the Carriage is out, move the Carriage to the left or right side, away from the jammed3.
paper.
Important
•
Do not touch the linear scale (A), carriage shaft (B), or ink tube stabilizer (C). Touching these may
•
cause malfunction.
754
To Next Page
