13-12 CLEANING AND MAINTENANCE April 2021
f. Gently lift up the Back Case approximately ½” above the Front Case and
carefully move the Back Case to the right and line up the Back Case with the
Front Case.
g. Replace the 4 hex-head screws.
4. Re-attach the Stand Base
Note: Reference CHAPTER 4:SYSTEM SETUP; SECTION:ASSEMBLY for
illustration.
a. On the previously removed 2 knobs, verify that a washer is over the shaft of
each knob.
b. Insert one of the knobs through one side of the Stand Base and place another
washer over the shaft of the knob (on the inside of the Stand Base).
c. With the front of the Readout facing the same direction as the front of the
Stand Base, place the Readout onto the Stand Base.
d. Insert the shaft of the knob into the mounting hole located on the side of the
Readout Unit. Loosely tighten the knob.
e. Insert the other knob with washer through the other side of the Stand Base
and place the other washer over the shaft of the knob (on the inside of the
Stand Base).
f. Insert the shaft of the knob into the mounting hole located on the other side of
the Readout Unit. Note: The sides of the Stand Base may need to be spread
apart a small amount to get the second knob to insert into the mounting hole.
g. Verify on each side that there is a washer between the knob and the Stand
Base (on the outside of the Stand Base), and the Stand Base and the
Readout (on the inside of the Stand Base).
h. The knobs can now be fully tightened.
5. System Power-Up
a. Reconnect the power cord and ALL other cables.
b. Turn on the power to the Readout Unit and verify that the “Low Battery”
message does not appear on the display.
6. Set the date and time as described in CHAPTER 5: SYSTEM INITIALIZATION.
