Section 6 — Parts
Part No. 750-363 6-17
Table 6-2. Dual Fuel Gas Trains SEE ILLUSTRATIONS FOLLOWING PAGES
SEE FIGURE 6-15
4000-5000 NATURAL GAS 4000-5000 PROPANE
1 817-02416-000 SWITCH, LOW GAS PRESSURE 8 817-02416-000 SWITCH, LOW GAS PRESSURE
2 817-02420-000 SWITCH, HIGH GAS PRESSURE 9 817-02420-000 SWITCH, HIGH GAS PRESSURE
3 825-00239-000 COCK, LEAKAGE TEST 10 825-00239-000 COCK, LEAKAGE TEST
4 918-00637-000 REGULATOR, GAS PRESS 11 918-00637-000 REGULATOR, GAS PRESS
5 940-07486-000 VALVE, GAS 12 940-07482-000 VALVE, GAS
6 941-01946-000 VALVE, BUTTERBALL 13 941-01946-000 VALVE, BUTTERBALL
7 941-01947-000 VALVE, BUTTERBALL 14 941-01947-000 VALVE, BUTTERBALL
SEE FIGURE 6-16 SEE FIGURE 6-17
6000-8000 NATURAL GAS 6000-8000 PROPANE
1 048-00888-000 ORIFICE, NATURAL GAS LINE 1 048-00921-000 ORIFICE, PROPANE LINE
2 941-01947-000 VALVE, BUTTERBALL 2 797-07943-000 ACTUATOR,GAS VALVE
4 797-07943-000 ACTUATOR,GAS VALVE,W/O POC 3 817-02416-000 SWITCH, LOW GAS PRESSURE
5 817-02416-000 SWITCH, LOW GAS PRESSURE 4 817-02417-000 SWITCH, HIGH GAS PRESSURE
6 817-02417-000 SWITCH, HIGH GAS PRESSURE 5 825-00239-000 COCK, LEAKAGE TEST
7 825-00239-000 COCK, LEAKAGE TEST 6 941-01947-000 VALVE, BUTTERBALL
10 945-00236-000 ACTUATOR, GAS VALVE, W/POC 7 945-00236-000 ACTUATOR, GAS VALVE, W/POC
11 949-00448-000 VALVE, GAS, MOTORIZED 8 949-00448-000 VALVE, GAS, MOTORIZED
10000 NATURAL GAS 10000 PROPANE
1 048-00914-000 ORIFICE, NATURAL GAS LINE 1 048-00934-000 ORIFICE, PROPANE LINE
2 223-00030-000 VALVE, BALL 2 797-07943-000 ACTUATOR,GAS VALVE,W/O POC
4 797-07943-000 ACTUATOR,GAS VALVE 3 817-02416-000 SWITCH, LOW GAS PRESSURE
5 817-02416-000 SWITCH, LOW GAS PRESSURE 4 817-02417-000 SWITCH, HIGH GAS PRESSURE
6 817-02417-000 SWITCH, HIGH GAS PRESS 12-60” WC 5 825-00239-000 COCK, LEAKAGE TEST
7 825-00239-000 COCK, LEAKAGE TEST 6 941-01947-000 VALVE, BUTTERBALL
10 945-00236-000 ACTUATOR,GAS VALVE,W/ POC 7 945-00236-000 ACTUATOR,GAS VALVE,W/ POC
11 949-00445-000 VALVE, GAS, MOTORIZED 8 949-00448-000 VALVE, GAS, MOTORIZED
12000 NATURAL GAS 12000 PROPANE
1 048-00878-000 ORIFICE, NATURAL GAS LINE 1 048-00933-000 ORIFICE, PROPANE LINE
2 223-00030-000 VALVE, BALL 2 797-07943-000 ACTUATOR,GAS VALVE,W/O POC
4 797-07943-000 ACTUATOR,GAS VALVE,W/O POC 3 817-02416-000 SWITCH, LOW GAS PRESSURE
5 817-02416-000 SWITCH, LOW GAS PRESSURE 4 817-02417-000 SWITCH, HIGH GAS PRESSURE
6 817-02417-000 SWITCH, HIGH GAS PRESSURE 5 825-00239-000 COCK, LEAKAGE TEST
7 825-00239-000 COCK, LEAKAGE TEST 6 941-01947-000 VALVE, BUTTERBALL
10 945-00236-000 ACTUATOR,GAS VALVE,W/ POC 7 945-00236-000 ACTUATOR,GAS VALVE,W/ POC
11 949-00445-000 VALVE, GAS, MOTORIZED 8 949-00448-000 VALVE, GAS, MOTORIZED
To Next Page
