Appendix B VSD Parameters
B-12
B.8 Drive Parameter List - PF 525
Parameters marked * must be changed from default
CFLC VSD Parameters - PF 525
Name
Parameter #
W/CFLC
Output Freq 001
Commanded Freq 002
Output Current 003
Output Voltage 004
Drive Status 006
Fault 1Code 007
Fault 2 Code 008
Fault3 Code 009
Process Display 010
Control Source 012
Contrl In Status 013
Dig In Status 014
Output RPM 015
Output Speed 016
Output Power 017
Power Saved 018
Elapsed Run Time 019
Average Power 020
Elapsed kWh 021
Elapsed MWh 022
Energy Saved 023
Accum kWh Sav 024
Accum Cost Sav 025
Accum C02 Sav 026
Drive Temp 027
Control Temp 028
Control SW Ver 029
Language 30
* Motor NP Volts 031 namplate
* Motor NP Hertz 032 namplate
* Motor OL Current 033 namplate
* Motor NP FLA 034 namplate
* Motor NP Poles 035 2
* Motor NP RPM 036 namplate
Motor NP Powert11 037
Voltage Class 038
Torque Perf Mode 039
Autotune 040
* Accel Time 1 041 20
* Decel Time 1 042 20
* Minimum Freq 043 12
* Maximum Freq 044 60
* Stop Mode 045 1, coast
* Sta rt Source 1 046 2, 2-wire
* Speed Reference1 047 6
StartSource 2 048
