Section 2 — Installation
Part No. 750-363 2-21
2.11 ELECTRICAL CONNECTIONS
A qualified electrician or service technician must make the electrical connections to the boiler.
For specific information on your boiler electrical system refer to the Cleaver-Brooks wiring diagram provided
with the boiler.
Power is to be run from the top left corner of the boiler to the control panel (see Figure 2-13). AC power is
to be connected to the incoming power terminals.
Note: The following temperature sensor cables should not be run near the three phase incoming power
wiring.
Hot water outlet temperature sensor.
Hot water return temperature sensor.
Stack temperature sensor (optional).
Outdoor temperature sensor (optional).
Header water temperature sensor (optional).
!
Warning
Ensure ignition cables are properly connected and not in direct contact with any sharp metal edges.
