Cleaver-Brooks ClearFire CFLC-5000 - CFLC Cutaway; Boiler Safety Valve(S) & Air Vent

Section 1 — Introduction
Part No. 750-363 1-5
Figure 1-5 CFLC Cutaway
Figure 1-6 Boiler safety valve(s) & air vent
TO STACK
Air Vent (optional)
LWCO probe holder
Safety Valve(s)
EX Tubes
Alufer Tubes
Control Panel
Gas Train
Burner
Assembly
Water
Return (2)
Water circulation
Combustion
gas flow
Furnace
Flue/
condensate
collection
chamber
Condensate
drain
Water Outlet
Boiler Drain
LWCO PROBE
HOLDER
GATE VALVE
AUTO AIR VENT
(OPTIONAL)
SAFETY VALVE(S)
