Cleaver-Brooks ClearFire CFLC-5000 - Gas Train (by model size and NOx)

Section 6 — Parts
Part No. 750-363 6-9
Figure 6-8 Gas train CFLC 4000/5000 (standard 20 PPM NOx)
DETAIL A
VIEW B-B
A
B
DESCRIPTIONPART NOQTYITEM
BUTTERBALL VALVE, BRONZE, 1-1/2" NPT.941-01946-000
1
6
ADAPTER, PIPE, 1-1/2" NPT. WITH SHUTTER, O-RING AND SCREWS
800-00104-00018
VALVE, GAS, COMBO, 120VAC940-07486-000
1
9
ADAPTER, PIPE, 2" NPT. WITHOUT SHUTTER
800-00102-000
1
10
REGULATOR, GAS PRESSURE, MAXITROL #210E, 2" NPT, 4"-12" WC (VIOLET)
918-00637-000
1
18
NIPPLE, SIDE OUTLET, 2" NPT. x 9" LG. x 1/2" NPT.
157-00425-000119
VALVE, BUTTERBALL, 2" NPT.941-01947-000
1
21
HIGH GAS PRESSURE SWITCH, 3-21"WC RANGE, MR, 1/4" NPT MOUNT
817-02420-000128
LGPS, 3-21"WC RANGE, MR, 1/4" NPT MOUNT817-02416-000
1
29
ADAPTER, 1/8 BSPT (MALE) x 1/8" NPT (FEMALE)
800-00103-000
4
30
LEAKAGE TEST COCK, 1/8" NPT.
825-00239-000331
FITTING, COMP. 90 DEG. ELBOW, 1/8" NPT. x 1/4" ODC
845-00217-000135
19
18
10
29
6
34
7
8
9
30
4
30
31
29
30 31
31
28
ASSEMBLY P/N
WHERE USED
DIM "A"
185-01245-000
CFLC 5000, 20PPM
.730"
185-01419-000
CFLC 5000, 9PPM
.657"
185-01420-000
CFLC 4000, 20PPM
.734"
185-01421-000
CFLC 4000, 9PPM
.665"
10
9
8
28
9
35
24
30
TO
VENTURI
GAS PILOT TRAIN
CONNECTION
DETAIL ITEM 8
ADJUST SHUTTER TO DIMENSION
PRIOR TO ASSEMBLING TO VALVE
"A"
