Appendix C Gas Valve
C-34
1
A
A
2
B
3 4
5
B
Changing coil
MBC-1000/2500
1. Shut o
gas s upply and
disconnect power s up -
ply!
2. Undo locking screw A, Fig. 1
3. R emove cover B, Fig. 2
4. E xchange solenoid, Fig. 3
Always observe s olenoid
No. and voltage!
5. R eplace cover B, tighten by
hand, Fig. 4
6. S crew in locking screw A to
stop, Fig. 5
