Cleaver-Brooks ClearFire CFLC-5000 - Pilot Gas Train

Section 6 — Parts
6-20 Part No. 750-363
Figure 6-19. Pilot Gas Train
ITEM DESCRIPTION PART NUMBER
1 COCK, GAS SERVICE, TEE HEAD SEE TABLE
2 VALVE, SOLENOID, GAS PILOT 235-00282
3 REGULATOR, GAS PRESSURE 918-00356
4 COCK, GAS SERVICE, TEE HEAD 825-00178
ITEM 1
CFLC 4000 - 5000 CFLC 6000 - 8000 CFLC 10000 - 12000
825-00029 825-00507 825-00029
4
3
2
1
