Appendix E Falcon Lead Lag
E-27
At each slave:
Use Boiler Pump control block (Figure 14) - assign to Pump B relay.
Use Aux 1 Pump (Figure 17) - assign to Pump C relay.
Figure 15 - Primary/Secondary Piping
Boiler 1 Boiler 2
SUPPLY
to system
System pumps -
controlled by others
Boiler
Pump
