Cleaver-Brooks ClearFire CFLC-5000 - Return Temperature Sensor (Rear Casing & Insulation Not Shown); Stack Outlet, Water Outlet, and Combustion Air Inlet

Section 1 — Introduction
1-6 Part No. 750-363
Figure 1-7 Return temperature sensor (rear casing & insulation not shown)
Figure 1-8 Stack Outlet, Water Outlet, and Combustion Air Inlet
STACK OUTLET
COMBUSTION AIR FILTER
WATER
OUTLET
OUTLET TEMP.
sensor well
