Cleaver-Brooks ClearFire CFLC-5000 - Page 140

Appendix B VSD Parameters
B-18
Freq 3llJ 514
Freq 3 BW' 11 515
Freq 1 Kp11J 521
Freq 1 Kil1J 522
Freq 2 Kp11i 523
Freq 2 Ki li 524
Freq 3 Ki111 526
Boost Select 530
Start Boost 531
Break Voltage 532
Break Frequency 533
Encoder PPR\11 536
Pulse I n Scale 537
Ki Speed Loop\ll 538
Kp Speed Loop' 11 539
Var PWM Disa ble 540
Auto Rstrt Tries 541
Auto Rstrt Delay 542
Start At PowerUp 543
Reverse Disable 544
Flying Start En 545
FlyStrtCurlimit 546
Compensation 547
Power Loss Mode 548
Half Bus Enable 549
Bus Reg Enable 550
Fault Clear 551
Program Lock 552
Program Lock Mod 553
Orv Ambient Sel 554
Reset Meters 555
Text Scroll 556
Out Phas Loss En 557
Positioning Mode 111 558
Counts Per Unitl1J 559
Home Save111 561
Find Home Freq11! 562
Find Home Dir 11 563
Encoder Pos ToJllJ 564
Pos Reg Filterl 11 565
Pos Reg Gainlll 566
Max Traverse 567
Traverse Inc 568
Traverse Dec 569
P J ump 570
Sync Time 571
Speed Ratio 572
Mtr Options Cfg 573
CFLC VSD Parameters - PF 525 (Continued)
Name
Parameter #
W/CFLC
