Appendix E Falcon Lead Lag
E-71
0=None,
1=Burner control,
2=Application,
3=Burner control & application,
4=Clear alert log
00B7 0183 Burner name R Variable length string (up to 20 characters)
00B8 0184 Installation data R Variable length string (up to 20 characters)
MODULATION CONFIGURATION
00C1 0193 CH maximum modulation rate R U16 RPM or %
00C2 0194 DHW maximum modulation
rate
R U16 RPM or %
00C3 0195 Minimum modulation rate R U16 RPM or %
00C4 0196 Prepurge rate R U16 SAFETY parameter: RPM or %
00C5 0197 Lightoff rate R U16 SAFETY parameter: RPM or %
00C6 0198 Postpurge rate R U16 SAFETY parameter: RPM or %
00C7 0199 CH forced rate R U16 RPM or %
00C8 0200 CH forced rate time R U16 0-64800 seconds (18 hours), 0xFFFF=Not configured
00C9 0201 DHW forced rate R U16 RPM or %
00CA 0202 DHW forced rate time R U16 0-64800 seconds (18 hours), 0xFFFF=Not configured
00CB 0203 Burner switch R/W U16 0=Off, 1=On. Used to enable/disable burner control.
00CC 0204 Firing rate control R U16 0=Auto, 1=Manual in Run, 2=Manual in Run&Standby
00CD 0205 Manual firing rate R U16 Firing rate used when control is set to manual (% or RPM)
CH CONFIGURATION
00D0 0208 CH enable R/W U16 0=Disable Central Heating, 1=Enable Central Heating
00D3 0211 CH setpoint R/W U16 -40°-130° (0.1°C precision)
00D4 0212 CH time of day setpoint R U16 -40°-130° (0.1°C precision) Setpoint when Time Of Day switch is on.
00D5 0213 CH on hysteresis R U16 0°-130° (0.1°C precision)
00D6 0214 CH off hysteresis R U16 0°-130° (0.1°C precision)
00D7 0215 CH outdoor reset enable R U16 0=Disable outdoor reset, 1=Enable outdoor reset
DHW CONFIGURATION
01C0 0448 DHW enable R/W U16 0=DHW disabled, 1=DHW enabled
01C5 0453 DHW setpoint R/W U16 -40°-130° (0.1°C precision)
01C6 0454 DHW time of day setpoint R U16 -40°-130° (0.1°C precision) Setpoint when Time Of Day switch is on.
01C7 0455 DHW on hysteresis R U16 0°-130° (0.1°C precision)
01C8 0456 DHW off hysteresis R U16 0°-130° (0.1°C precision)
LIMITS CONFIGURATION
01D0 0464 Outlet high limit setpoint R U16 SAFETY parameter: -40°-130° (0.1°C precision)
01D3 0467 Stack limit setpoint R U16 SAFETY parameter: -40°-130° (0.1°C precision)
01D7 0471 Delta-T inlet/outlet degrees R U16 Temperature delta between inlet & outlet sensors when Delta-T limit
occurs: 0°-130° (0.1°C precision)
01DB 0475 DHW high limit setpoint R U16 SAFETY parameter: -40°-130° (0.1°C precision)
OUTDOOR RESET (ODR) CONFIGURATION
0200 0512 CH ODR maximum outdoor
temperature
R U16 -40°-130° (0.1°C precision)
0201 0513 CH ODR minimum outdoor tem-
perature
R U16 -40°-130° (0.1°C precision)
0202 0514 CH ODR low water temperature R U16 -40°-130° (0.1°C precision)
0203 0515 CH ODR boost time R U16 0-64800 seconds (18 hours), 0xFFFF=Not configured
0204 0516 CH ODR boost maximum set-
point
R U16 -40°-130° (0.1°C precision)
0205 0517 Lead Lag ODR maximum out-
door temperature
R U16 -40°-130° (0.1°C precision)
0206 0518 Lead Lag ODR minimum out-
door temperature
R U16 -40°-130° (0.1°C precision)
0207 0519 Lead Lag ODR minimum water
temperature
R U16 -40°-130° (0.1°C precision)
0208 0520 Lead Lag ODR boost time R U16 0-64800 seconds (18 hours), 0xFFFF=Not configured
0209 0521 Lead Lag ODR boost maximum
setpoint
R U16 -40°-130° (0.1°C precision)
020A 0522 CH ODR boost step R U16 0°-130° (0.1°C precision)
020B 0523 CH ODR boost recovery step
time
R U16 0-64800 seconds (18 hours), 0xFFFF=Not configured
020C 0524 Lead Lag ODR boost step R U16 0°-130° (0.1°C precision)
FROST PROTECTION CONFIG-
URATION
