InteliDrive – Engine ECU communication
Hint:
Cummins MODBUS engines are not supported in InteliDrive.
Example of standard J1939 engine
List of possible J1939 analog data that can be configured to received in ID-DCU MARINE.
Name
Engine speed
RPM
Actual torque
%
Demand torque
%
Coolant temp
°C
EngineOil temp
°C
Boost Pressure
bar
Intake Manifold Temp
°C
Air Intake pressure
bar
Exhaust Gas Temp
°C
Accelerator Pedal position
%
Percent Load
%
Fuel Rate
L/h
EngOil Filter Diff.Press
bar
Battery Potential (Voltage)
V
Fuel Delivery Pressure
bar
Engine Oil level
%
Crankcase Pressure
bar
Coolant Pressure
bar
Coolant Level
%
Fault reset = accepts (confirms) diagnostic message = removes inactive message form ECU Alarm list only
when ECU Alarm list is visible.
Hint:
Fault reset button is “screen sensitive”. It is active only on selected actual controller screen.
