InternetBridge-NT
Width x Height x Depth 180x130x45mm
Weight 450g
Power supply range 8-36VDC
Average power consumption approx. 400mA@8V; 120mA@36V
Peak power consumption approx. 1,5A@8V; 0,5A@36V
Operating temperature -20 to +60°C (-4 to 140°F)
Storage temperature
(without SIM card; ask your operator for SIM card
storage/operation conditions) -40 to +80°C (-40 to 176°F)
Ethernet socket 100Base-TX, automatic negotiation
Cellular modem capabilities GPRS, EGPRS, UMTS, HSPA
Cellular modem GPRS bands 850, 900, 1800, 1900MHz
Cellular modem UMTS bands 800, 850, 1700, 1900, 2100MHz
This device is class A device as defined
in the standard EN 55022 (for commercial areas).
It complies with following standards: EMC emissions: ETSI EN 301489-1
EMC immunity: EN 61000-4-2,
EN 61000-4-3, EN 61000-4-4,
EN 61000-4-5, EN 61000-4-6
