ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 164 -
ID-DCU-MARINE-2.2.2.pdf
IS-AIN8
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Max. consumption 250 mA
Mechanical dimensions: 150 x 160 x 50 mm ,
DIN rail (35 mm) mounted
Connection to ID-DCU Marine (galvanically separated) CAN1
Operating temperature -30..+70
o
C
Storage temperature -40..+80
o
C
Protection front panel IP 20
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Analog inputs
Number of inputs 8
Not galvanic separated
Resolution 16 bits
Each analog input can be software configured to:
Measuring range
Accuracy
From
to
Resistance
0 
2400 
± 0,5 %
0 
250 
± 1,0 %
Current
Passive
0 / 4 mA
20 mA
± 0,5 %
Active
4 mA
20 mA
± 0,5 %
Active
0 mA
± 20 mA
± 0,5 %
Voltage
Thermocouples J, K, L type
± 0,2 %
0 mV
100 mV
± 0,2 %
- 1000 mV
+ 1000 mV
± 0,5 %
0 mV
2500 mV
± 0,5 %
Hint:
Sensors must be isolated from the engine body (except for thermocouples (since HW version 5.0)). Follow
rear sticker description and remove the appropriate jumpers in case of thermocouples not isolated from the
engine body.
IS-AIN8TC
Dimension (WxHxD) 146x160x46 mm (5.79’x6.6’x1.83’)
Interface to controller CAN1
Analog inputs 8, no galvanic separated, 16bit *
Power supply 8 to 36 V DC
Current consumption 250mA at 24 V
Protection front panel IP20 Humidity 95% without condensation
Storage temperature – 40°C to + 80°C
Operating temperature – 30°C to + 70°C
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Accuracy
Voltage - Thermocouples J, K, L type ± 0,2 %
