ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 75 -
ID-DCU-MARINE-2.2.2.pdf
Source: Info
CAN16 1 … CAN16 16 (PRP only)
Indication of separate bits in Info: CAN16 value indicating the active communicating controllers on CAN2
bus. E.g. 11000000 value indicates there are two controllers communicating on CAN2 - addresses 1 and 2.
ECU Alarms 1-1 … ECU Alarms 1-16
ECU Alarms 2-1 … ECU Alarms 2-16
ECU Alarms 3-1 … ECU Alarms 3-16
ECU Alarms 4-1 … ECU Alarms 4-16
Separate ECU Alarms (bits) indication of following objects. The link between each ECU Alarm and bit
position in ECU Alarm x is in corresponding esf (esc) file. Now it is supported for Volvo engines only.
Bit
ECU Alarms 1
Obj.no. 10916
ECU Alarms2
Obj.no. 10917
ECU Alarms3
Obj.no. 10918
ECU Alarms4
Obj.no. 10919
1
EngCool Press
#N/A
5V DC Fail
SAE J1939 fail
2
Fuel Press
#N/A
Pickup Failure
J1939 Datalink
3
Water in fuel
#N/A
Timing Failure
J1939 Bus
4
Oil Level
#N/A
Starter Output
SAE J1587 fail
5
Oil Diff Press
#N/A
Primary Batt
Prg MemoryFail
6
EngOil Press
#N/A
Secondary Batt
CalibrMem fail
7
Boost Press
#N/A
15 supply
Controller#1
8
Intake Temp
#N/A
30 supply
EMSSupply10A
9
AirInletPress
#N/A
EMS supply
ExtraSupply7A
10
EngCool Temp
#N/A
Extra supply
30Supply7A
11
Coolant Level
Injector 1
BattPotential
#N/A
12
CrankcasePress
Injector 2
ExtSTOP Active
#N/A
13
Exhaust Temp
Injector 3
D12SeaWatPres
#N/A
14
EngineOil Temp
Injector 4
D12ExhTemp
#N/A
15
Piston CoolPr
Injector 5
PrimBatActive
#N/A
16
SeaWater Press
Injector 6
SecBatActive
#N/A
