ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 7 -
ID-DCU-MARINE-2.2.2.pdf
General description
InteliDrive DCU Marine is a specialized engine controller for Marine applications. It controls, monitors and
protects the engine in single (Auxiliary) or variable (propulsion) speed operational modes. The controller can
communicate with Engine Management System via the CAN serial line using standard J1939 or another
(KWP2000) communication protocol.
InteliDrive controllers are equipped with a powerful graphic display with icons, symbols and bar-graphs for
intuitive operation, which together with high functionality sets new standards in engine controls.
Engine functions
 Engine sequencing and control (start/stop, warm-up and cool-down, pre-lubrication etc.)
 Engine monitoring and protections (2 or more level analog inputs protection, adjustable delays)
 Speed measurement from magnetic pick-up or from ECU
 Running hours meter, number of starts counter
 Configurable 14 Binary inputs and Outputs and 8 Analog inputs
 Setpoints are adjustable via InteliDrive panel or via PC software
 3 level password protection
 On screen Alarm and ECU Alarm indication
 Event and time driven engine history for back tracing
 Two or more languages selectable in controller
Communication
 RS232 / Modbus RTU
 Analog or GSM modem
 Internet
 Engines with Engine Electronic Control Unit: J1939, J1587, KWP2000
 Extension units for more I/O and Remote Display panel.
Physical
 180x120 mm front panel mounted case
 Graphic back-lit LCD display 128x64 pixel resolution with icons and bar graphs
 LED status indicators / Lamp test
ID – RPU Redundant Protection Unit
 1 Emergency stop input
 5 Shutdown inputs
 1 RPM input
 Common warning and common shutdown output terminals
 Stop solenoid, fuel solenoid outputs
 Redundant power supply
 I/O broken wire detection
Conformity declaration
Following described machine complies with the appropriate basic safety and health
requirement of the EC Low Voltage Directive No: 73/23 / EEC and EC Electromagnetic
Compatibility Directive 89/336 / EEC based on its design and type, as brought into
circulation by us.
