InteliDrive – Redundancy Protection Unit = ID backup unit for Overspeed and
Emergency stop protection in Marine applications.
InteliDrive – Speed Control Module = interface unit for InteliDrive controller.
InteliGen – Internet Bridge = controller interface for internet communication.
InternetBridge-NT = communication module with cellular/Ethernet connection.
Remote Annunciator = external 15 LED indication panel (three colors,
configurable).
InteliGen – Modem Unit (older type) = controller interface for multiple engines
application – one point communication with group of controllers connected via
CAN2.
Controller extension module with 8 binary inputs and outputs and 4 analog inputs.
InteliMonitor, PC software for InteliDrive monitoring.
PC software for InteliDrive monitoring.
Inteli IO8/8 extension module.
Inteli Relay board = interface board with 8 free contact relays.
Inteli Relay board = interface board with 16 free contact relays.
Inteli Remote Display (Remote Panel) = the same panel like on controller, all data
received via CAN2 bus.
Inteli Remote Display (Remote Panel) = the same panel like on controller, all data
received via CAN2 bus.
Inteli Remote Display (Remote Panel) = the same panel like on controller, all data
received via CAN2 bus.
InteliSys – Analog input module = extension module with 8 analog inputs.
InteliSys – Thermocouple analog input module = extension module with 8
thermocouple analog inputs.
Inteli Analog input module = 8 analog inputs and 1 RPM/Impulse input.
Inteli Thermocouple Analog input module = 8 thermocouple analog inputs.
InteliSys – Binary input/output module = extension module with 16 binary inputs
and 8 binary outputs.
The J1587 bus is mainly used for redundant signals; system diagnosis and
software download on aftermarket tools.
The J1939 bus in mainly used for engine controls and engine monitoring.
Scania Communication protocol.
Extension for controller firmware (Motorola HeX file).
Message Identification Assignments.
Controller mode when power supply is switched on, but all binary outputs and start
commands are disabled = engine start is blocked.
J1939 Parameter Identification Assignments.
J1939 Proprietary Parameter Identification Assignments.
Controller Propulsion mode.
Engine Revolution Per Minute – engine speed.
J1939 Proprietary Parameter Identification Assignments.
Standard serial data line for PC or Modem connection (controller programming or
monitoring).
J1939 Subsystem Identification Assignments.
