ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 102 -
ID-DCU-MARINE-2.2.2.pdf
Access code
 Can be changed from InteliMonitor software only (Monitor – Change Access code).
 Has to be set before remote modem or SMS connection is opened.
 Can be up to 16 ASCII characters
At first Password 3 has to be entered before the new Access code can be changed.
Engine commands and Statistics protection
Commands (Engine Cmd) password protection protects Start, Horn reset, Fault reset commands from
controller front panel buttons, remote displays, MODBUS line or InteliMonitor.
Selected Command password level 0, 1, 2, 3 is valid for all engine commands except of Stop. Stop
command is password protected separately by “Engine Stop” option.
Separately can be also protected statistic commands: ClearStatistics, SetSucc starts, EngRun hours,
SetUnsuc starts.
To set commands protection from DriveConfig:
Open DriveConfig
Select Commands window
Set Password = 0 (no protection) or level 1 or 2 or 3
Hint:
Engine commands password protection works according to the description above from firmware version
ID-DCU MARINE 2.1 and firmware versions of remote displays listed below. In older firmware versions
“Engine Cmd” group contains also Stop command, commands from ID-DCU MARINE local panel (buttons
directly on the controller) were not password protected in older versions.
I-RD-CAN-ID-DCU-MARINE – from 2.3
InteliVision 5 CAN (Backlit) – from 1.3
InteliVision 8 (Marine) – depends on screen configuration in archive of ID-DCU MARINE controller. Default
archives for ID-DCU MARINE version 2.1 and higher support independent password protection of Stop
command according to description above.
Hint:
All setpoints below can be modified from Remote panel or InteliMonitor as well.
Basic settings
Engine Name
User defined name, used for InteliDrive controller identification at remote phone or mobile connection.
Engine name is max 14 characters long and have to be entered manually using InteliMonitor software.
Hint:
Engine name is not changed when new archive is loaded. Check Engine name after firmware upgrade.
Mode ID [ OFF, AUX ]
Mode ID [ OFF, EME ]
Mode ID [ OFF, EME, HRB ]
Mode ID [ OFF, PRP ]
Equivalent to Controller mode changes by Mode-> or <-Mode buttons.
Hint:
Mode change can be separately password protected.
Mode can be changed by binary input Remote OFF or Remote HRB.
