Clutch Del [ s ]
Time between the clutch is switched on/off and the load sharing function is activated.
Step: 0,1 s
Range: 0,0 – 10,0 s
ClutchMinSpeed, ClutchMaxSpeed [ % ]
Clutch can be switched on if ClutchMinSpeed < RPM < ClutchMaxSpeed. Limits are in % of Requested
speed. See Requested RPM, Overload protection in chapter ID-DCU MARINE functions.
Step: 0,1 %
Range: 0,0 – 100,0 %
Hint:
0,0% corresponds to (Idle speed + Idle offset) value, 100,0% corresponds to Nominal speed.
Back Up Speed [ % ]
See loadsharing block diagram - the setpoint value is used instead of Engine Values: Speed Request in
loadsharing state if Binary input Back Up Speed is active and the Logical Analog Input Requested RPM via
analog input is out of range (sensor fail is detected).
Step: 0,1 %
Range: 0,0 – 100,0 %
MaxClStrPer [ s ]
Engine clutch start protection. Start fail alarm is activated if engine running condition is not detected
MaxClStrPer delay after Binary output Clutch Connect is closed.
Step: 1 s
Range: 0 – 600 s
DetectOtherCAN [ DISABLED, ENABLED ]
Enables wrn message when no other unit is recognized on the CAN bus. Binary output OthrCommEr is
closed in this case.
Analog inputs
AIN1 Offset … AIN8 Offset
Adjustable offset for AIN1 to AIN8 for calibrating purposes.
Active call/SMS
Warning Call [ DISABLED, ENABLED ]
Enables or disables active calls/SMS to selected phone or mobile numbers when a Warning alarm occurs.
Shut Down Call [ DISABLED, ENABLED ]
Enables or disables active calls to selected phone or mobile numbers when a Shutdown alarm occurs.
