IS-AIN8
Extension module with 8 analog inputs. All inputs can be configured to any logical function or protection - see
chapter Analog inputs.
IS-AIN8 module is connected on InteliDrive CAN1 bus. The corresponding module Address must be set on
module and in controller configuration. Communication fail is indicated in controller Alarm list and by binary
output Comm AIN fail. Use DriveConfig PC tool for controller configuration.
The analog inputs specification see in chapter Technical data.
