ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 162 -
ID-DCU-MARINE-2.2.2.pdf
Recommended Industrial Automation & Process Control Cables:
BELDEN (see http://www.belden.com):
 3082A DeviceBus for Allen-Bradley DeviceNet
 3083A DeviceBus for Allen-Bradley DeviceNet
 3086A DeviceBus for Honeywell SDS
 3087A DeviceBus for Honeywell SDS
 3084A DeviceBus for Allen-Bradley DeviceNet
 3085A DeviceBus for Allen-Bradley DeviceNet
 3105A Paired EIA Industrial RS485 cable
LAPP CABLE (see http://www.lappcable.com)
 Unitronic BUS DeviceNet Trunk Cable
 Unitronic BUS DeviceNet Drop Cable
 Unitronic BUS CAN
 Unitronic-FD BUS P CAN UL/CSA
IS-BIN16/8
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Max. consumption 250 mA
Mechanical dimensions: 150 x 160 x 50 mm,
DIN rail (35 mm) mounted
Connection to ID-DCU MARINE (galvanically separated) CAN1
Operating temperature -30..+70
o
C
Storage temperature -40..+80
o
C
Protection front panel IP 20
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Binary inputs
Galvanically separated two groups
Number of inputs 8 + 8
Input resistance 3 k
Input voltage range 0-36 VDC
Input voltage level for open contact 8 to Power supply VDC
Input voltage level for close contact 0 to 2 VDC
Voltage level is defined between Binary input and Binary input COM terminal.
Open collector outputs
Number of outputs (galvanically separated) 8
Maximum current 0,5 A
Maximum switching voltage 36 VDC
Frequency inputs
Number of inputs 2 (RPM1, RPM2)
RPM1
Type of sensor magnetic pick-up
Minimum input voltage 2 Vpk-pk (from 4 Hz to 4 kHz)
Maximum input voltage 50 Veff
Maximum measured frequency 8 kHz (min. input voltage 6Vpk-pk), frequency mode
