ID-DCU-MARINE-2.2.2, ©ComAp June 2015 - 79 -
ID-DCU-MARINE-2.2.2.pdf
SwitchToBatt B
It is closed when ID-RPU was switched power supply to the battery B.
Start Blocking
Start blocking indication.
ClutchBlocking
Clutch blocking indication.
Source: Ana protections
List of Analog inputs protection indication is dynamic. Any protection configured e.g. on Analog input appears
in Source: Ana protection Binary output list.
Source: Bin protections
List of Binary inputs protection - indication is dynamic. Any protection configured on Binary input appears in
Source: Bin protection.
Source: Binary Inputs CU
Binary CU list contains all ID-DCU MARINE binary inputs that can be configured to Binary outputs. This
source contains binary inputs physical states (no protection activity).
Source: RPU unit
Following list contains ID-RPU Shut down inputs state that can be configured to Binary outputs.
RPU-SD 1
Indication of ID-RPU Shut down 1 input state.
