Page #165 background image
ID-DCU-MARINE-2.2.2, ©ComAp June 2015 - 165 -
ID-DCU-MARINE-2.2.2.pdf
Inteli AIN8
Dimension (WxHxD) 110x110x46 mm (4,3”x4,3”x1,8”)
Interface to controller CAN1
Analog inputs (not electric separated) 8 channels
Voltage range 0-10V accuracy: ± 0,25 % of actual value + ± 25 mV
current range: ±20mA accuracy: ± 0,25 % of actual value + ± 50 μA
resistance range: 0- 10kΩ accuracy: resistance: ± 0,5 % of actual value + ± 2 Ω
Pt100, Pt1000, Ni100, Ni1000 ± 2,5 °C
Galvanic separation CAN bus is galvanic separated from the
measurement and power supply All analog inputs
are galvanic separated from power supply Analog
inputs are not galvanic separated between channels
Power supply 8 to 36 V DC
Protection IP20
Current consumption 35 mA at 24V ÷ 100 mA at 8V
Storage temperature - 40°C to + 80°C
Operating temperature - 30°C to + 70°C
Inteli AIN8TC
Dimension (WxHxD) 110x110x46 mm (4,3”x4,3”x1,8”)
Interface to controller CAN 1
Analog inputs (not electric separated) 8, no galvanic separation
Measuring: Voltage range ± 100 mV
Accuracy: ± 0,1 % of actual value + ± 100 μV (± 3 °C)
Internal sensor for measuring cold junction:
Accuracy: ±1 °C in temperature range -20 °C ÷ +70 °C
Galvanic separation CAN bus is galvanic separated from the
measurement and power supply All analog inputs
are galvanic separated from power supply Analog
inputs are not galvanic separated between channels
Power supply 8 to 36 V DC
Protection IP20
Current consumption 35 mA at 24V ÷ 100 mA at 8V
Storage temperature - 40°C to + 80°C
Operating temperature - 30°C to + 70°C
IGL-RA15
Power supply
Nominal power supply 24 VDC
Power supply range 8 36 VDC
Consumption 0,35 - 0,1A (+1A max horn output)
Depend on supply voltage
