ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 158 -
ID-DCU-MARINE-2.2.2.pdf
Technical data
ID-DCU MARINE
Power supply
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Current consumption (depends on supply voltage) 0,34A at 8VDC
0,12A at 24VDC
0,09A at 36VDC
Galvanically isolated from controller body YES
Battery voltage measurement tolerance 2 % at 24V
RTC battery life-cycle 10 year
Hint:
RTC battery flat causes wrong Date&Time information only.
Operating conditions
Operating temperature ID-DCU MARINE -20 to +70 °C
Operating temperature ID-DCU-LT -40 to +70 °C
Storage temperature -30 to +80 °C
Humidity 95% without condensation
Flash memory data retention time 10 years
Protection front panel IP65
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 61000-6-2, October 2001
EN 61000-6-4, October 2001
IEC 60533, Ed. 2; 1999-11
Vibration 5 - 25 Hz, ±1,6mm
25 - 100 Hz, a = 4 g
Shocks a = 200 m/s2
Dimensions and weight
Dimensions (183x123x47mm)
See chapter terminals and dimensions
Weight 800g
Binary inputs
Number of inputs 14
Input impedance 4,7 k
Input range 0-36 VDC
Switching voltage level for close contact indication 0-2 V
Voltage level for open contact indication 8-36 V
Minimal input duration 110 ms
Binary open collector outputs
Number of outputs 14
Maximum current - outputs BO1, BO2 1A
Maximum current - outputs BO3 - BO14 0,5 A
Maximum switching voltage 36 VDC
