I-CB communication bridge
I-CB (Communication bridge) is programmable CAN1 bus interface between InteliDrive and Engine Control
Units (like MTU, CAT etc.) without standard J1939 communication protocol. Engine values from ECU (RPM,
Oil pressure and other) are converted to standard InteliDrive I/O protocol.
Use ICBEdit software for I-CB configuration.
POWER
8-36V DC
COM
RS 232
LB 4
i-CB
95 mm
(3,7´´)
43 mm
(1,7´´)
96 mm (3,8´´)
