ComAp InteliDrive DCU Marine Reference Guide

ID-DCU-MARINE-2.2.2, ©ComAp – June 2015 - 166 -
ID-DCU-MARINE-2.2.2.pdf
Operating conditions
Operating temperature -20..+70
o
C
Storage temperature -30..+80
o
C
Protection front panel IP65
Dimensions and weight
Dimensions 180x120x55mm
Weight 950g
Horn output
Maximum current 1 A
Maximum switching voltage 36 VDC
IGS-PTM
Nominal power supply 24 VDC
Power supply range 8 – 36 VDC
Max. consumption 100 mA
Mechanical dimensions: 40 x 95 x 45 mm, DIN rail (35 mm) mounted
Interface to controller CAN
Operating temperature -30..+70
o
C
Binary inputs
Number of inputs 8
Input resistance 4,7 k
Input range 0 - 36 VDC
Switching voltage level for close contact indication 0 - 2 V
Max voltage level for open contact indication 8-36 V
Binary open collector outputs
Number of outputs 8
Maximum current 0,5 A
Maximum switching voltage 36 VDC
Analog inputs
Not electrically separated
Number of inputs 4
Resolution 10 bits
Maximal resistance range 0 – 250 
Maximal voltage range 0 – 100 mV
Maximal current range 0 – 20 mA
Resistance measurement tolerance 1 %  2  out of measured value
Voltage measurement tolerance 1,5 %  1mV out of measured value
Current measurement tolerance 2,5 %  0,5mA out of measured value
Analog output
Not electrically separated
Number of inputs 1
Resolution 10 bits
Output range 0 to 20 mA ± 0,33 mA
