Analog outputs
Source: Basic Settings
Engine RPM
Current engine speed.
EngRPMfiltered
Filtered current engine speed for nice displaying without nozzle oscillations.
Mode Loc
Text string value containing "LOC" or empty text string depending on Activated or Deactivated LOC mode.
Source: Engine Values
Speed Request
Internal Speed Request value which can be used to control engine speed. See following flow charts how the
Speed Request value is generated in case of PRP or AUX/EME/HRB mode.
