StopButtEcho
1 sec pulse is generated after panel Stop button is pressed.
FltResButtEcho
1 sec pulse is generated after panel Fault reset button is pressed. The pulse is generated only in case that
Alarm List screen is displayed on the controller, i.e. in the time of possibility to acknowledge alarms.
HrnResButtEcho
1 sec pulse is generated after panel Horn reset button is pressed.
ClutchButtEcho
1 sec pulse is generated after panel I/0 button is pressed.
ActLoadShar
Indication of active Load sharing.
User Button 1 … User Button 16
InteliVision function buttons can be assigned to these LBOs User Button 1 .. 16. The configuration of
button’s functionality is done via Screen Editor feature in DriveConfig PC application.
RemoteControl1 … RemoteControl8
Those eight LBOs can be handled from InteliMonitor Remote switch window. This way can operator directly
handle controller binary outputs or other e.g. PLC functions.
