D-Link DWL-3600AP User Manual

ManagingClientQoSACLs
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page136
UnifiedAccessPointAdministrator’sGuide
IPTOSMask EnteranIPTOSmaskvaluetoidentifythebitpositionsintheTOSBitsvaluethatare
usedforcomparisonagainsttheIPTOSfieldinapacket.
TheTOSMaskva lueisatwo‐digithexadecimalnumberfrom00toff,representing
aninverted(i.e.wildcard)
mask.Thezero‐valuedbitsintheTOSMaskdenotethe
bitpositionsintheTOSBitsvaluethatareusedforcomparisonagainsttheIPTOS
fieldofapacket.Forexample,tocheckforanIPTOSvaluehavingbits7and5set
andbit1clear,where
bit7ismostsignificant,useaTOSBitsvalueofa0andaTOS
Maskof00.Thisisanoptionalconfiguration.
IPv6ACL
Protocol SelecttheProtocolfieldtouseanL3orL4protocolmatchconditionbasedonthe
valueoftheIPProtocolfieldinIPv4packetsor
theNextHeaderfieldofIPv6packets.
Onceyouselectthefield,choosetheprotocoltomatchbykeywordorprotocolID.
SourceIPv6Address Selectthisfieldtorequireapacket'ssourceIPv6addresstomatchtheaddresslisted
here.EnteranIPv6addressintheappropriatefieldtoapplythis
criteria.
SourceIPv6PrefixLength EntertheprefixlengthofthesourceIPv6address.
SourcePort Selectthisoptiontoincludeasourceportinthematchconditionfortherule.The
sourceportisidentified inthedatagramheader.
Onceyouselecttheoption,choosetheportnameorentertheport
number.
DestinationIPv6Address Selectthisfieldtorequireapacket'sdestinationIPv6addresstomatchtheaddress
listedhere.EnteranIPv6addressintheappropriatefieldtoapplythiscriteria.
DestinationIPv6Prefix
Length
EntertheprefixlengthofthedestinationIPv6addre ss.
DestinationPort Selectthisoptiontoincludea
destinationportinthematchconditionfortherule.
Thedestinationportisidentifiedinthedatagramheader.
Onceyouselecttheoption,choosetheportnameorentertheportnumber.
IPv6FlowLabel Flowlabelis20‐bitnumberthatisuniquetoanIPv6packet.Itisusedby
end
stationstosignifyquality‐of‐servicehandlinginrouters(range0to1048575).
IPv6DSCP TouseIPv6DSCPasamatchcriteria,selectthecheckboxandselectaDSCPvalue
keywordorenteraDSCPvaluetomatch.Youcanselectonlyoneservicetype(DSCP,
IPPrecedenceor
TOSbits)touseformatchcriteria.
SelectfromList
SelectfromalistofDSCPtypes.
MatchtoValue
EnteraDSCPValuetomatch(0–63).
Table53:ACLConfiguration(Cont.)
Field Description

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
