ManagingClientQoSACLs
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page137
UnifiedAccessPointAdministrator’sGuide
Afteryousetthedesiredrulecriteria,clickApply.TodeleteanACL,selecttheDeleteACLoptionandclick
Apply.
MACACL
EtherType SelecttheEtherTypefieldtocomparethematchcriteriaagainstthevalueinthe
headerofanEthernetframe.
SelectanEtherT ypekeywordorenteranEtherType
valuetospecifythematch
criteria.
SelectfromListSelect
Selectoneofthefollowingprotocoltypes:
• appletalk
•arp
•ipv4
•ipv6
•ipx
•netbios
• pppoe
MatchtoValue
Enteracustomprotocolidentifiertowhichpack etsarematched.Thevalueisafour‐
digithexidecimalnumberintherangeof0600–FFFF.
ClassofService Selectthisfield
andenteran802.1puserprioritytocompareagainstanEthernet
frame.
Thevalidrangeis0–7.Thisfieldislocatedinthefirst/only802.1QVLANtag.
SourceMACAddress SelectthisfieldandenterthesourceMACaddresstocompareagainstanEthernet
frame.
SourceMACMask Selectthisfield
andenterthesour ceMACaddressmaskspecifyingwhichbitsinthe
sourceMACtocompareagainstanEthernetframe.
A0indicatesthattheaddressbitissignificant,andanfindicatesthattheaddress
bitistobeignored.AMACmaskof00:00:00:00:00:00matchesasingleMAC
address.
DestinationMAC
Address
SelectthisfieldandenterthedestinationMACaddresstocompareagainstan
Ethernetframe.
DestinationMACMask EnterthedestinationMACaddressmaskspecifyingwhichbitsinthedestination
MACtocompareagainstanEthernetframe.
A0indicatesthattheaddressbitissignificant,andanf
indicatesthattheaddress
bitistobeignored.AMACmaskof00:00:00:00:00:00matchesasingleMAC
address.
VLANID SelectthisfieldandentertheVLANIDstocompareagainstanEthernetframe.
Thisfieldislocatedinthefirst/only802.1QVLANtag.
Table53:ACLConfiguration(Cont.)
Field Description
