VirtualAccessPointSettings
D-Link UnifiedAccessPointAdministrator’sGuide
November2011 Page72
UnifiedAccessPointAdministrator’sGuide
RADIUSKey EntertheRADIUSkeyinthetextbox.
TheRADIUSKeyisthesharedsecretkeyfortheglobalRADIUSserver.Youcanuseupto
63standardalphanumericandspecialcharacters.Thekeyiscasesensitive,andyoumust
configurethesamekeyontheAPandonyour
RADIUSserver.Thetextyouenterwillbe
displayedas“*”characterstopreventothersfromseeingtheRADIUSkeyasyoutype.
RADIUSKey1–3 EntertheRADIUSkeyassociatedwiththeconfiguredbackupRADIUSservers.Theserver
atRADIUSIPAddress‐1usesRADIUSKey‐1,RADIUS
IPAddress‐2usesRADIUSKey‐2,and
soon.
EnableRADIUS
Accounting
Selectthisoptiontotrackandmeasuretheresourcesaparticularuserhasconsumed
suchassystemtime,amountofdatatransmittedandreceived,andsoon.
IfyouenableRADIUSaccounting,itisenabledfortheprimaryRADIUS
serverandall
backupservers.
EnableRADIUS
FailThrough
SelectthisoptiontoallowthesecondaryRADIUSservertoauthenticatewire lessclients
iftheauthenticationwiththeprimaryRADIUSserverisunsuccessful,oriftheprimary
RADIUSserverisunavailable.
Radio Selecttheradiotoconfigure.VAPsareconfiguredindependentlyoneachradio.
Note:
TheDWL‐3600APsupportsonlyoneradio.
VAP Youcanconfigureupto16VAPsforeachradio.VAP0isthephysicalradiointerface,soto
disableVAP0,youmustdisabletheradio.
Enabled Youcanenableordisableaconfigurednetwork.
•Toenablethespecifiednetwork,selecttheEnabledoptionbesidethe
appropriate
VAP.
•Todisablethespecifiednetwork,cleartheEnabledoptionbesidetheappropriate
VAP.
Ifyoudisablethespecifiednetwork,youwilllosetheVLANIDyouentered.
VLANID WhenawirelessclientconnectstotheAPbyusingthisVAP,theAPtagsalltrafficfrom
thewirelessclient
withtheVLANIDyouenterinthis fieldunlessyouentertheuntagged
VLANIDoruseaRADIUSservertoassignawirelessclienttoaVLAN.Therangeforthe
VLANIDis1–4094.
IfyouuseRADIUS‐basedauthenticationforclients,youcanoptionallyadd
thefollowing
attributestotheappropriatefileintheRADIUSorAAAservertoconfigureaVLANforthe
client:
• “Tunnel‐Type”
• “Tunnel‐Medium‐Type”
• “Tunnel‐Private‐Group‐ID”
TheRADIUS‐assignedVLANIDoverridestheVLANIDyouconfigureontheVAPpage.
YouconfiguretheuntaggedandmanagementVLANIDs
ontheEthernetSettingspage.
Formoreinformation,see“EthernetSettings”onpage51.
SSID Enteranameforthewirelessnetwork.TheSSIDisanalphanumericstringofupto32
characters.YoucanusethesameSSIDformultipleVAPs,oryoucanchooseauniqueSSID
foreach
VAP .
Note:IfyouareconnectedasawirelessclienttothesameAPthatyouareadministering,
resettingtheSSIDwillcauseyoutoloseconnectivitytotheAP.Youwillneedtoreconnect
tothenewSSIDafteryousavethisnewsetting.
Table22:VirtualAccessPointSettings(Cont.)
Field Description
