User's Manual
114
5.5.5 Configuring Overlay Settings
Background Information
You can configure to display system time and channel name on each channel window in the live
view screen.
Procedure
Step 1 Select
Main Menu
>
CAMERA
>
Overlay
>
Overlay
.
Figure 5-68 Overlay
Step 2 Configure the settings for the text overlay parameters.
Table 5-27 Overlay parameters
Parameter Description
Channel
In the
Channel
list, select the channel that you want to configure the
settings for.
Time Title
Select the
Time Title
checkbox to display the system time on each
channel window in the live view screen.
In the
Time Title
list, select time display style.
Channel Title
Select the
Channel Title
checkbox to display the channel name on each
channel window in the live view screen.
In the
Channel Title
box, enter the name for the selected channel.
Step 3 Click
Apply
to complete the settings.
