Procedure
Step 1 After you have configured the encode settings, on the
Encode
page, click
Next
.
Figure 5-24 Snapshot
Step 2 Configure the settings for the snapshot parameters.
Table 5-7 Snapshot parameters
Parameter Description
Manual Snapshot
In the
Manual Snapshot
list, select how many snapshots you want to
take each time.
Channel
In the
Channel
list, select the channel that you want to configure the
settings for.
Type
In the
Mode
list, you can select
Human Face
,
Event
, or
General
as the
event type for which you want to take a snapshot.
●
Scheduled
: The snapshot is taken during the scheduled period.
●
Event
: The snapshot is taken when there is an alarm event occurs,
such as motion detection event, video loss, and local alarms.
●
Face Snapshot:
The snapshot is taken when the face is detected.
The face detection function is support only with the Channel 1.
Size
In the
Size
list, select a value for the image. The bigger the value is, the
better the image will become.
Quality
Configure the image quality by 6 levels. The higher the level is, the
better the image will become.
Interval Configure or customize the snapshot frequency.
5.1.4.8 Configuring Basic Storage Settings
You can configure the settings for the situations when HDD is full, file length and time length of
recorded video, and the settings if to auto-delete the old files.
You can also configure basic storage settings by selecting
Main Menu
>
STORAGE
>
Basic
.
