User's Manual
264
Parameter Description
Port Mapping List
The settings in PAT table correspond to the UPnP PAT table on the
router.
●
Service Name: Name of network server.
●
Protocol: Type of protocol.
●
Int. Port: Internal port that is mapped on the Device.
●
Ext. Port: External port that is mapped on the router.
●
To avoid the conflict, when setting the external port, try to
use the ports from 1024 through 5000 and avoid popular
ports from 1 through 255 and system ports from 256 through
1023.
●
When there are several devices in the LAN, reasonably
arrange the ports mapping to avoid mapping to the same
external port.
●
When establishing a mapping relationship, ensure the
mapping ports are not occupied or limited.
●
The internal and external ports of TCP and UDP must be the
same and cannot be modified.
●
Click to modify the external port.
Step 3 Click
Apply
to complete the settings.
In the browser, enter http://
WAN IP: External IP port
. You can visit the LAN Device.
5.15.1.9 Configuring SNMP Settings
You can connect the Device with some software such as MIB Builder and MG-SOFT MIB Browser to
manage and control the Device from the software. This function is available on select models.
Prerequisites
●
Install the software that can manage and control the SNMP, such as MIB Builder and MG-SOFT
MIB Browser
●
Obtain the MIB files that correspond to the current version from the technical support.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
SNMP
.
