User's Manual
266
Step 4 Run MG-SOFT MIB Browser to load in the module from compilation.
Step 5 On the MG-SOFT MIB Browser, enter the Device IP that you want to manage, and then
select the version number to query.
Step 6 On the MG-SOFT MIB Browser, unfold the tree-structured directory to obtain the
configurations of the Device, such as the channels quantity and software version.
5.15.1.10 Configuring Multicast Settings
When you access the Device from the network to view the video, if the access is exceeded, the video
will not display. You can use the multicast function to group the IP to solve the problem.
Procedure
Step 1 Select
Main Menu
>
NETWORK
>
Multicast
.
Figure 5-228 Multicast
Step 2 Configure the settings for the multicast parameters.
Table 5-63 Multicast parameters
Parameter Description
Enable Enable the multicast function.
IP Address
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.
Port Enter the port for the multicast. The port ranges from 1025 through 65000.
Step 3 Click
Apply
to complete the settings.
You can use the multicast IP address to log in to the web.
On the web login dialog box, in the
Type
list, select
MULTICAST
. The web will
automatically obtain the multicast IP address and join. Then you can view the video
through multicast function.
