User's Manual
169
Parameter Description
PTZ Linkage
Click
Setting
to display the PTZ page.
Motion Detect can only activate PTZ preset.
Post Record
Set a length of time for the Device to delay turning off recording after
the alarm is cancelled. The value ranges from 10 seconds to 300
seconds, and the default value is 10 seconds.
Tour
Select the
Tour
checkbox to enable a tour of the selected channels.
Picture Storage
Select the
Snapshot
checkbox to take a snapshot of the selected
channel.
To use this function, select
Main Menu
>
CAMERA
>
Encode
>
Snapshot
, in the
Type
list, select
Event
.
Sub Screen
Select the checkbox to enable the function. When an alarm event
occurs, the extra screen outputs the settings configured in
Main
Menu
>
DISPLAY
>
Tour
>
Sub Screen
.
●
This function is available on select models.
●
To use this function, extra screen shall be enabled.
Video Matrix
Select the checkbox to enable the function. When an alarm event
occurs, the video output port outputs the settings configured in
Main
Menu
>
DISPLAY
>
Tour
.
This function is available on select models.
Buzzer Select the checkbox to activate a buzzer noise at the Device.
Log Select the checkbox to enable the Device to record a local alarm log.
Alarm Tone
Select to enable audio broadcast/alarm tones in response to a motion
detection event.
Warning Light Select the checkbox to enable warning light alarm of the camera.
Siren Select the checkbox to enable sound alarm of the camera.
Step 3 Click
Apply
to save the settings.
●
Click
Default
to restore the default setting.
●
Click
Copy to
, in the
Copy to
dialog box, select the additional channel(s) that you want
to copy the motion detection settings to, and then click
Apply
.
●
Click
Test
to test the settings.
5.10.4.1.1 Setting the Motion Detection Region
Procedure
Step 1 Next to
Region
, click
Setting
.
Step 2 Point to the middle top of the page.
To Next Page
