User's Manual
303
5.19.3 Attack Defense
5.19.3.1 Firewall
Procedure
Step 1 Select
Main Menu
>
SECURITY
>
Attack Defense
>
Firewall
.
Step 2 Select
Enable
to enable firewarll.
Step 3 Configure the parameters.
Table 5-73 Firewall parameters
Parameter Description
Mode
Mode can be configured when Type is Network Access.
●
If Allowlist is enabled, you can visit device port
successfully with IP/MAC hosts in the allowlist.
●
If Blocklist is enabled, you cannot visit device port with
IP/MAC hosts in blocklist.
Add
When
Type
is
Network Access
, you can configure IP
Address, IP Segment and MAC Address.
Type You can select IP address, IP segment and MAC address.
IP Address Enter IP Address, Start Port and End Port that is allowed or
forbidden.
When
Type
is
IP Address
, they can be configured.
Start
Port
and
End Port
can be configured only in
Network
Access Type
.
Start Port
End Port
Start Address/End Address
Enter Start Address and End Address of IP Segment.
When
Type
is
IP Segment
, they can be configured.
MAC Address
Enter MAC Address that is allowed or forbidden
When
Type
is
MAC Address
, it can be configured.
Step 4 Click
Apply
.
5.19.3.2 Account Lockout
Procedure
Step 1 Select
Main Menu
>
SECURITY
>
Attack Defense
>
Account Lockout
.
Step 2 Set parameters.
