User's Manual
255
Parameter Description
Refresh
Refresh the hotspot list. The self-adaption function such as
adding password is supported if such setting was once
configured.
Connect
In the hotpots list, select a hotspot, and then click
Connect
.
●
To reconnect the same hotspot, disconnect first and then
reconnect.
●
To connect to other hotspot, disconnect from the current
connected hotspot first, and then connect to the other
hotspot.
Disconnect To disconnect from a hotspot, click
Disconnect
.
Step 3 (Optional) Click
Firmware Update
, select related firmware file, and then click
OK
.
Step 4 Click
Apply
to complete the settings.
After the Device is connected to a Wi-Fi hotspot, in the
Wi-Fi Info
area, the current
hotspot, IP address, subnet mask, and default gateway are displayed.
5.15.1.4 Configuring 3G/4G Settings
5.15.1.4.1 Through the Wireless 3G/4G Module
You can connect a wireless 3G/4G module to the USB port of the Device and then access the Device
with the IP address provided by the module.
This function is available on select models.
Procedure
Step 1 Connect the wireless 3G/4G module to the USB port of the Device.
Step 2 Select
Main Menu
>
NETWORK
>
3G/4G
.
