User's Manual
209
Parameter Description
Tour
Select the
Tour
checkbox to enable a tour of the selected
channels.
●
To use this function, the tour setting must be configured.
●
After the tour is ended, the live view screen returns to the
view layout before tour started.
Picture Storage
Select the
Picture Storage
checkbox to take a snapshot of the
selected channel.
To use this function, make sure the snapshot function is enabled
for
Intel
in
Main Menu
>
STORAGE
>
Schedule
>
Snapshot
.
Video Matrix
Select the checkbox to enable the function. When an alarm event
occurs, the video output port outputs the settings configured in
Main Menu
>
DISPLAY
>
TOUR
>
Extra Screen
.
●
This function is available on select models.
●
The extra screen must be enabled to support this function.
Buzzer Select the checkbox to activate a buzzer noise at the Device.
Log
Select the checkbox to enable the Device to record a local alarm
log.
Alarm Tone
Select to enable audio broadcast in response to a face detection
event.
Warning Light
Select the checkbox to enable the warning light alarm of the
camera.
Siren Select the checkbox to enable the sound alarm of the camera.
Smart Illumination
Select the checkbox to enable the smart illumination of the
camera.
Step 5 Click
OK
to save the settings.
Step 6 Select the
Enable
checkbox, and then click
Apply
.
The tripwire detecting function is active. When the target object crosses the tripwire in the
defined direction, the system activates alarms.
5.11.2.3.3 Configuring Intrusion Rules
When the target enters and leaves the defined detection area, or the target appears in the defined
area, the system activates alarms.
●
You can define the shape and quantity of intrusion areas.
●
Supports detecting the behaviors that enter and leave the intrusion areas.
●
Supports detecting the behaviors that are moving in the intrusion areas. The quantity of areas
and lasting time can be configured.
●
Supports size filtering for target.
Procedure
