User's Manual
137
Parameter Description
Main Stream/Sub
Stream
Auto
: Automatically record according to the record type and
recording time as configured in the recording schedule.
Manual
: Keep general recording for 24 hours for the selected
channel.
Stop
: Do not record.
Snapshot
Enable or disable the scheduled snapshot for the corresponding
channels.
Step 3 Click
Apply
.
5.7.2 Configuring Recorded Video Storage Schedule
You need to configure the storage schedule for the recorded video so that the recorded video can
be saved. For details, see "5.1.4.9 Configuring Recorded Video Storage Schedule".
5.8 Configuring Snapshot Settings
5.8.1 Configuring Snapshot Trigger
The snapshot is divided into scheduled snapshot, event triggered snapshot, and face detection
triggered snapshot. When the both are enabled, the event triggered snapshot has the priority.
If there is no alarm event, the system performs scheduled snapshot.
If there is any alarm event, the system performs event triggered snapshot.
5.8.1.1 Configuring Scheduled Snapshot
Procedure
Step 1 Right-click on the live view screen, the shortcut menu is displayed.
Step 2 On the shortcut menu, select
Manual Control > Record Control
.
Step 3 In the
Snapshot
area, enable the snapshot for the channels if needed.
