User's Manual
310
5.19.6 Security Warning
5.19.6.1 Security Exception
Procedure
Step 1 Select
Main Menu
>
SECURITY
>
Security Warning
>
Security Exception
.
Figure 5-286 Security exception
Step 2 Select
Enable
and then configure the parameters.
Table 5-79 Security exception parameters
Parameter Description
Alarm-out Port
The alarm device (such as lights, sirens, etc.) is connected to the alarm
output port. When an alarm occurs, the DVR device transmits the alarm
information to the alarm device.
Post-Alarm
When the alarm ends, the alarm extended for a period of time. The time
range is from 0 seconds to 300 seconds.
Show Message Checkbox to enable a pop-up message in your local host PC.
Buzzer Select the checkbox to activate the buzzer when an alarm occurs.
Alarm Tone
Check the box and then select the corresponding audio file from the
dropdown list. System plays the audio file when the alarm occurs.
Log
Select the checkbox, the DVR device records the alarm information in
the log when an alarm occurs.
