User's Manual
241
Figure 5-205 Temperature/Humidity
Step 2 On the humidity information line, click .
Figure 5-206 Setting
Step 3 Configure the settings for the following parameters.
Table 5-51 Alarm settings
Parameter Description
Access Point Indicates the channel that the camera is connected to.
Type
Humidity
by default.
Detect Position Name Set the detect position name.
Preview Channel
Select the channel that you want to preview to help monitor the
channel of access point. This channel could be the channel of
access point or any other channels according to your actual
situation.
Event Type
Select event type as
High Humidity
or
Low Humidity
, and set
