RAPID CONFIGURATION
18 MATRIX 320
7. Now select the General Image Settings branch and click on the Focus Autolearn
button.
8. The Calibrate dialog box opens allowing you to start the procedure. Click Start.
The Reading Distance value is not sig-
nificant until the Focus Autolearn pro-
cedure ends successfully.
